Bottom Cover Assembly

This bottom cover assembly is part of a full workflow I created in 2025, automating a weeklong task into the course of roughly 30 minutes. Using a highly parametrized skeleton assembly in Inventor, alongside integration with the Tacton CAD configurator, this assembly slots in effectively to a range of product configurations. Additionally, by implementing captive hardware, this assembly improves safety compliance globally.


Maker Techniques:

Parametric Assembly Design

CAD Configurators (TACTON)

Autodesk Inventor Weldment Design

Captive Hardware

International Team Collaboration
